Metal Sensor
Price:
€2.76
incl. 23% TAX, excl. shipping costs
Regular price:
The lowest price during 30 days prior to the reduction:
・Kup teraz i zapłać za 30 dni
product unavailable
Availability:
wycofany z oferty
Czujnik wykrywający kontakt z metalowymi przedmiotami.
Overview
- Sensitive to metal (only when in contact with metals)
- Features wide range voltage comparator LM393
- Adjustable sensitivity
- Signal output indicator
Specifications
- Power: 3.3V ~ 5.3V
- Dimension: 27.3mm * 15.4mm
- Mounting holes size: 2.0mm
Applications
- Metal detection
- Smart car
- Electronic bricks
How to Use
In the case of working with a MCU:
- VCC ↔ 3.3V ~ 5.3V
- GND ↔ power supply ground
- AOUT ↔ MCU.IO (analog output)
- DOUT ↔ MCU.IO (digital output)
Package Contains
- Metal Sensor × 1
- 4-pin custom connector jumper wire × 1
Downloads
Development resources: demo codes, schematic, datasheets, etc.
Click here to download
