Płyta bazowa dla SIM900
product unavailable
Description
Overview
GPRS module is a breakout board and minimum system of SIM900 Quad-band GSM/GPRS module. It can communicate with controllers via AT commands (GSM 07.07 ,07.05 and SIMCOM enhanced AT Commands). This module support software power on and reset.
Features
- Quad-Band 850/ 900/ 1800/ 1900 MHz
- GPRS multi-slot class 10/8GPRS mobile station class B
- Compliant to GSM phase 2/2+Class 4 (2 W @850/ 900 MHz)
- Class 1 (1 W @ 1800/1900MHz)
- Control via AT commands (GSM 07.07 ,07.05 and SIMCOM enhanced AT Commands)
- Low power consumption: 1.5mA(sleep mode)
- Operation temperature: -40°C to +85 °C
Hardware
Specification
Module Type | Wireless |
Weight | 40.00g |
Model | IM120525010 |
Board Size | 6.4 x 5.1 x 1.2cm |
Version | 1 |
Operation Level | Digital 5V |
Power Supply | External 12V External 24V External 9V |
Useful Links
Link: https://github.com/jgarland79/GSM_Shield
Uwaga zestaw nie zawiera anteny.
