Zigbee coordinator and router 3.0 Ethernet PoE Wi-Fi USB CC2652P7 SMLIGHT SLZB-06P7U

Zigbee coordinator and router 3.0 Ethernet PoE Wi-Fi USB CC2652P7 SMLIGHT SLZB-06P7U

SMLIGHT SLZB-06P7U is a versatile Zigbee 3.0 and Thread network adapter, designed to work with home automation platforms such as Home Assistant or Zigbee2MQTT. The device connects to the host system via wired Ethernet (including PoE power), wirelessly via Wi-Fi, or locally using a USB port.

Key features:

Flexible connectivity and power over Ethernet (PoE)

The SLZB-06P7U adapter allows for free selection of the installation method depending on the conditions in the building. Thanks to support for the PoE 802.3af power standard, the device can receive power and transmit data using a single network cable connected to a PoE switch. In places without wired network infrastructure, the module can connect via a wireless Wi-Fi network or directly via a USB cable to a computer or server, and power can then be supplied from a standard USB Type-C port.

Stable signal and high computing power

The use of the Texas Instruments CC2652P7 chip with 152 KB RAM guarantees high responsiveness even in extensive smart home installations. The built-in radio path with a 20 dB gain amplifier, along with an omnidirectional 5 dB antenna with three-plane adjustment, makes it easier to bypass structural obstacles and ensures stable coverage for large living areas.

Multitasking and openness to modifications

Thanks to the pre-installed open-source software, the adapter is ready to work immediately after connection. The firmware can be conveniently updated wirelessly (OTA) via a web browser panel or via a USB cable. The user can change the device role at any time, transforming the coordinator into a router to extend the range of an existing Zigbee network.

Technical specification

Kit contents

Frequently Asked Questions (FAQ)

• What is SMLIGHT SLZB-06P7U?
  It is a universal adapter that acts as a communication bridge between devices operating in the Zigbee or Thread standard and a home automation hub, e.g., Home Assistant. It supports Ethernet, Wi-Fi, and USB connections.
• Is a PoE power supply included in the kit?
  No, neither a power supply nor a PoE switch is included in the kit. The device is compliant with the 802.3af standard and can be powered from an existing PoE network or alternatively from any USB Type-C power source.
• How can I switch operating modes between coordinator and router?
  Changing the operating mode involves uploading the appropriate firmware variant, which can be done remotely via the built-in web interface or locally via a USB cable.
• Does the adapter work directly with Home Assistant?
  Yes, the device has pre-installed software and is factory-prepared for immediate cooperation with Home Assistant ZHA and Zigbee2MQTT add-ons.
• Can the SLZB-06P7U work as a Matter-over-Thread router?
  Yes, the adapter allows operation as a Matter-over-Thread router in combination with an Ethernet network and the OpenThread Border Router add-on.
