SONOFF Bridge Max Matter Zigbee smart home bridge 3.0
Regular price:
・Kup teraz i zapłać za 30 dni
product unavailable
SONOFF Bridge Max Smart Home Gateway | Bridge-M
The SONOFF Bridge Max is a versatile smart home gateway that connects Zigbee, BTHome, and eWeLink ecosystems with leading Matter platforms such as Apple Home, Alexa, or Google Home. Thanks to a local web interface, support for up to 128 Zigbee devices, and a built-in alarm siren with a volume of 90 dB, it serves as an advanced and reliable control center for your home automation without the need for constant cloud reliance.
Key features:
- Support for the Matter protocol: Seamless integration of Zigbee, BTHome, and eWeLink devices with Apple Home, Alexa, Google Home, or Home Assistant.
- Local web interface: Configuration and connection of devices on the local network without the need to download additional applications or register in the cloud.
- Efficient Zigbee gateway: Ability to connect and manage up to 128 devices on a single hub.
- Alarm functions and security: Built-in 90 dB siren with the ability to trigger alarms from sensors and cameras.
- Support for Home Assistant: Device synchronization via MQTT or integration with Matter ecosystems.
One gateway for Matter ecosystems
Thanks to the Matter Bridge function, devices communicating via Zigbee, Wi-Fi, eWeLink-Remote, and BTHome can be seamlessly integrated with platforms supporting Matter. This allows for unified home control and the creation of advanced automations between devices from different manufacturers (support for Apple Home, SmartThings, Alexa, and others).
Local management panel
Connect many types of devices to Matter ecosystems using a clear web interface (Dashboard) available on your local network. The panel allows for convenient management of connected equipment and monitoring of their status in real time. Note: The web panel is used only for device configuration and synchronization (direct control is not possible).
Apple ecosystem expansion and Zigbee compatibility
Using Matter functionality, even devices that do not natively support HomeKit certification can be seamlessly integrated with the Apple environment. Additionally, the Bridge Max works with all SONOFF Zigbee devices and supports a wide range of third-party sensors and switches.
Technical specification
- Model: Bridge-M (Bridge Series)
- Microcontroller: SigmaStar_SSD2351Q + EFR32MG21
- Power input: 5V 1A (USB Type-C connector)
- Wi-Fi connectivity: IEEE 802.11 a/b/g/n/ac/ax
- Zigbee connectivity: IEEE 802.15.4
- Network interface: RJ45 (10/100 Mbps)
- Net weight: 83,4 g
- Dimensions: 82 x 82 x 28 mm
- Housing material: PC + ABS
- Operating environment: Indoor
- Operating temperature: -10°C ~ 40°C
- Permissible humidity: 5% ~ 95% RH (non-condensing)
Package contents
- SONOFF Bridge Max Gateway | Bridge-M
Frequently Asked Questions (FAQ)
- Where can I find the list of devices supported by the gateway?
A detailed compatibility table for the Bridge Max is available on the page: List of supported devices. - Does the gateway work only via Wi-Fi, without an Ethernet cable?
The gateway supports both standards. If you do not have the option to connect an Ethernet cable, you can easily configure a wireless Wi-Fi connection via the eWeLink app. - Can I transfer my devices from other Zigbee gateways?
Currently, the automated data migration function is supported only for the older ZBBridge-P gateway model.
